Save more power with the smallest PMIC for AMOLED display
Related Products

BV6805
WL-CSP-16B
NEW
BV6805 is a highly integrated SIBO AMOLED PMIC featuring a maximum output current of 150mA and dynamic-OVSS.
Vin Range
3.4V ~ 5V
Vout Range
-3.3V ~ 3.3V
Max Iout
0.15A
Output Rail
AVDD/OVDD/OVSS

BV6811
WL-CSP-12B
NEW
New Generarion SIBO PMIC for Wearable AMOLED with ±2.8V output voltage and Max. 100mA output current.
Vin Range
2.7V ~ 5.5V
Vout Range
-2.8V ~ 2.8V
Max Iout
0.1A
Output Rail
AVDD/OVDD/OVSS

BV6813
WL-CSP-12B
NEW
BV6813 is a SIDO PMIC for new type LTPO AMOLED with Max. output current 100mA.
Vin Range
2.9V ~ 5.5V
Vout Range
2.6V ~ 8.4V
Max Iout
0.1A
Output Rail
VCI / VDDEL

BV6801
WL-CSP-16B
ACTIVE
BV6801 is a SIBO AMOLED PMIC with ±2.8V output voltage and Max. 100mA output current.
Vin Range
2.9V ~ 5.5V
Vout Range
-2.8V ~ 2.8V
Max Iout
0.1A
Output Rail
AVDD/OVDD/OVSS

BV6802/A
WL-CSP-16B
ACTIVE
BV6802 is a SIBO AMOLED PMIC with 2.8V/4.6V/-2.4V output voltage and Max. 100mA output current.
Vin Range
2.9V ~ 5.5V
Vout Range
-2.4V ~ 4.6V
Max Iout
0.1A
Output Rail
AVDD/OVDD/OVSS

BV6803
WL-CSP-16B
ACTIVE
BV6803 is a highly integrated power solutions with SIBO, and LDO to generate two positive and one negative output voltages.
Vin Range
2.9V ~ 5.5V
Vout Range
-3.3V ~ 3.3V
Max Iout
0.1A
Output Rail
AVDD/OVDD/OVSS

BV6804
WL-CSP-16B
ACTIVE
BV6804 is a SIBO AMOLED PMIC with ±3.3V output voltage and Max. 100mA output current.
Vin Range
3.4V ~ 5.5V
Vout Range
-3.3V ~ 3.3V
Max Iout
0.1A
Output Rail
AVDD/OVDD/OVSS

BVP62840
FCDFN-8L 2.0mmx1.5mm
ACTIVE
Ultra-low Quiescent Current 120nA, 2.5V to 5.5V, 750mA
Synchronous Step-Down Converter
Synchronous Step-Down Converter
Vin Range
2.5V ~ 5.5V
Vout Range
1.8V ~ 3.3V
Max Iout
0.75A
Output Rail
Single Buck

BVP62841
FCDFN-8L 2.0mmx1.5mm
ACTIVE
Ultra-low Quiescent Current 120nA, 2.5V to 5.5V, 750mA
Synchronous Step-Down Converter
Synchronous Step-Down Converter
Vin Range
2.5V ~ 5.5V
Vout Range
0.8V ~ 1.55V
Max Iout
0.75A
Output Rail
Single Buck

BV6806
WL-CSP-16B
NEW
BV6806 is a highly integrated SIBO AMOLED PMIC featuring a maximum output current of 150mA and dynamic-OVSS.
Vin Range
2.9V ~ 5V
Vout Range
-3.3V ~ 3.3V
Max Iout
0.15A
Output Rail
AVDD/OVDD/OVSS
